Ceramic Glaze Stains Pr-Yellow for pottery decoration

FULLN CHEMICAL ceramic glaze stain Pr Yellow FU-3501 (Zirconium praseodymium yellow) pigment is a kind of high temperature calcining synthetic inorganic ceramic pigment. It's composed of praseodymium oxide, quartz, zirconium dioxide, mineralizer and other raw material through mixing, firing, micro powder processing. It is a yellow inorganic pigment. In the process of high temperature calcination, zirconium oxide (IV), silica (IV) and praseodymium oxide (Pr6O11) with different number of homogeneous, ionization mutual diffusion, form the zircon crystal structure. Its composition also contains one or more of alkali metal halide or a combination of the alkaline earth metal halide. FULLN CHEMICAL ceramic glaze stain Pr Yellow is suitable in oxidizing atmosphere firing and suitable for all kinds of glazes especially zirconium glazes. Glazes contain too much calcium composition are not conductive to the color.

With completed production process and advanced testing equipment, strict quality control system and strong talent team we can ensure that our ceramic glaze pigment have full ranges of colors and stable quality. These series of ceramic glaze stain Pr Yellow materials are with fineness of less than 400 mesh, moisture is less than 0.5%. Fulln ceramic glaze stain Pr Yellow can be used in the field of ceramic floor tiles, ceramic wall tiles, art porcelains, sanitary wares, etc.

During the production of tableware ceramics, if you have restrictions on the content of heavy metals in the pigment, please feel free to contact us. We can prepare ceramic glaze stain(CICP,Complex Inorganic Color Pigment) products that meet the requirements of our customers.

Pr-Yellow FU-3501 is an exceptional choice for anyone seeking a bright, stable, and reliable yellow pigment for ceramic applications. Whether for household items, artistic creations, or industrial ceramics, this pigment delivers outstanding performance, ensuring your products stand out with their brilliant and enduring color.

APPLICATIONS

Ceramics

Pottery

Sanitary ware

Tableware

Artware

Bricks

Porcelain

The preparation of praseodymium yellow material consists of: The electrofused zirconia particles were ground into zirconia powder with particle size of 3~5 m and homogenized. The active adhesive with particle diameter of 1-1.5 was obtained by mixing the mixture of lithium sodium and mg-CA mixtures in accordance with 7:4 weight ratio and then through high temperature melting, water quenching, water washing to neutral, drying and grinding. The high temperature melting temperature is 1300 °C. The zirconia powder is mixed with the active adhesive and the amount of the active adhesive is 0.05wt % of the total amount of the mixture. The zirconia powder was treated at 200°C and 2MPa for 10h to completely bond with the active adhesive. The modified zirconia was obtained by improving the reaction activity of the electrofused zirconia. The other auxiliary materials of the modified electrofused zirconia and praseodymium yellow materials were fully mixed evenly, and calcined in the bowl under the oxidizing atmosphere at a heating rate of 160°C/h. When the calcination temperature reached 1000°C, the heat preservation was held for 2 hours, and then cooling, grinding, washing and drying were performed to obtain praseodymium yellow materials.

Hot Tags: Ceramic Glaze Stains Pr-Yellow for pottery decoration, China, manufacturers, suppliers, factory, custom, wholesale, bulk, in stock,CICP，Complex Inorganic Color Pigment, ceramics colours, Ceramic Glaze Pigments Coral Pink, Ceramic Glaze Colors Silver Gray, Ceramic Glaze Colors Mytle Blue, Ceramic Glaze Pigments V Yellow, Ceramic Glaze Colors Gray
